ISOSTATIC, TP STEEL-BACKED PTFE LINED THRUST WASHER LEAD FREE
WM50TP, (706415 ISO) 52 MM I.D. x 78 MM O.D. x 2.0 MM Length, METRIC
FEATURES & BENEFITS
Self-lubricating dry sliding bearingA steel-backed composite material comprised of: low carbon steel backing allowing for extremely high load capacity - thickness .50-2.7mm; sintered bronze offering optimal heat dispersion - thickness .20-.35mm and PTFE LEAD FREE sliding surface creates a low friction coefficient and allows for wide temperature range - thickness .02mmCan be used where many liquid lubricants fail; also performs well with lubricationEffective in temperature range of -328 degree F to + 536 degree F with standard oilMax PV 102,000, P-Load 36,250, V-SFM 1,900Interchangeable with GARLOCK DP4 type bearingsRoHS, REACH, EVL, WEEE AND DFARS compliantHarmonized Tariff Code (HTC) 7318.29.0000Alternative Part Numbers: WC50DP4
Unit of Measure: EA
Package Quantity: 1
SPECIFICATIONS
