ISOSTATIC, OILUBE OIL IMPREGNATED BRONZE CORED CIRCULAR DISC

CD-5500, (103104 ISO) 2 IN I.D. x 5-1/2 IN O.D. x 1/4 IN Thick, INCH

Product made with excess material to finish to stated nominal ID and OD dimensions

SAE 841-Copper (87-90%), tin (8-9%), carbon and other elements

Powdered metal bronze vacuum impregnated with oil

Self-lubricating - when in motion oil rises to the surface for lubrication and restores itself when at rest

Effective in temperature range of +10 degree F to +175 degree F with standard oil

Max PV 50,000, P-Load 2,000, V-SFM 1,200

RoHS, REACH, DFARS, Conflict Minerals compliant

Made in USA

Harmonized Tariff Code (HTC) 7403.22.0000

Alternative Part Numbers: CD5500, CD5500
Unit of Measure: EA
Package Quantity: 1
SPECIFICATIONS

MSDS SHEET

CD-5500

Qty

$216.40
